Day 3 · Networking III — SSH & Firewalls

You can address a machine and resolve its name — now you need to get into it, safely. SSH is the single most-used tool in a DevOps engineer's day: every server, every deploy, every debug session starts with it. Today you'll go past "type a password" to key-based login, config shortcuts, and a hardened server, then how teams reach fleets of machines (VPNs and bastion hosts) — and finally a firewall that closes every door you're not using.

Learning Objectives

• Hand-type a protocol with telnet (HTTP, SMTP) — and see why plaintext login gave way to SSH
• Generate SSH key pairs and authorize them via ~/.ssh/authorized_keys
• Streamline connections with ~/.ssh/config, and move files with scp and rsync
• Harden an SSH server — disable passwords and root login
• Understand how VPNs and bastion hosts give teams access at scale
• Lock a host down to only the ports it needs with ufw

---

Prerequisites

Today's lab runs on a single Ubuntu VM. Save this as a Vagrantfile, then vagrant up and vagrant ssh in — you'll run the whole lab from inside this VM, SSHing to itself as a stand-in for a remote server.

Vagrant.configure("2") do |config|
  config.vm.box      = "bento/ubuntu-24.04"
  config.vm.hostname = "server"

  config.vm.network "private_network", ip: "192.168.56.11"

  config.vm.provider "virtualbox" do |vb|
    vb.name   = "server"
    vb.memory = 1024
    vb.cpus   = 1
  end
end

vagrant up        # create/start the VM
vagrant ssh       # log in — run the whole lab from here

---

Theory · ~20 min

1. Telnet — typing a protocol by hand

A protocol like HTTP or SMTP is just agreed-upon text sent over a TCP connection. Because telnet gives you a raw TCP pipe plus your keyboard, you can be the client and type that text yourself — a genuinely handy way to poke at a service and see exactly what it says back. Ask a web server for a page over HTTP (port 80):

$ telnet example.com 80
GET / HTTP/1.1        ← request line: method, path, HTTP version
Host: example.com     ← required header
                      ← blank line ends the request → server sends the page back

Or hand a message to a mail server over SMTP (port 25) — each line gets a numeric reply code (250 OK, 550 rejected…):

$ telnet mail.example.com 25
HELO myclient.local
MAIL FROM:<you@example.com>      ← the < > are required by the SMTP grammar
RCPT TO:<friend@example.com>
DATA
Subject: Hi from telnet

Typed by hand over TCP.
.                                ← a lone dot on its own line ends the message
QUIT

The server can't tell your keystrokes from a real browser or mail client — it only sees bytes on the socket, and that's the whole point: a protocol is just agreed-upon text over a TCP stream. (Two gotchas that bite everyone: SMTP requires the < > around addresses, and pressing Ctrl-] drops you to a local telnet> prompt — telnet's own command mode — where quit closes a stuck session.)

Telnet was also how you logged into servers — and why SSH replaced it

Before SSH, telnet <host> 23 dropped you straight into a login shell on a remote machine — it was the original remote-access tool. The fatal flaw: everything, including your password, crossed the network as plaintext, with no way to verify the server's identity or detect tampering. SSH encrypts the entire session, proves the server's identity with a host key, and adds key-based auth — which is why it completely replaced telnet for logins.

2. SSH — secure login and file transfer

Anything you do on a server now, you do over SSH (Secure Shell): a single encrypted, authenticated channel that carries interactive shells, one-off commands, and file copies.

📺 Watch — SSH Tutorial: Crash Course (Marco Codes, ~30 min)

A hands-on tour of everything in this section — watch it before the lab, then jump back to any part you're stuck on.

Chapters: SSH overview · ssh-keygen · authorized_keys · scp · ssh-agent · ~/.ssh/config · agent forwarding · SSH tunnels

ssh user@host            # log in (encrypted interactive shell)
ssh user@host 'uptime'   # run one command and return

The host-key prompt is SSH proving the server's identity

The first time you connect, SSH shows the server's host key fingerprint — the "The authenticity of host … can't be established" prompt. Accept it once and SSH records it in ~/.ssh/known_hosts; if that key ever changes, SSH loudly refuses to connect, catching the impersonation that telnet couldn't. (After a legitimate change — a rebuilt server — clear the stale entry with ssh-keygen -R <host> and reconnect.)

Keys beat passwords

Passwords can be guessed, phished, and brute-forced. Key-based authentication replaces them with a key pair:

• Private key (~/.ssh/id_ed25519) — stays on your machine, secret, never shared.
• Public key (~/.ssh/id_ed25519.pub) — copied onto the server, into ~/.ssh/authorized_keys. Safe to hand out.

You (private key)                    Server (your public key on file)
      │  "I want in"                        │
      │ ───────────────────────────────────▶
      │            challenge                │
      │ ◀───────────────────────────────────
      │  signs it with the private key      │
      │ ───────────────────────────────────▶  verifies with the public key → in

The private key never crosses the wire. This is why every cloud provider hands you a key pair, not a password, for a new server.

~/.ssh/authorized_keys — the server's guest list

On the server, the account you log in as has a ~/.ssh/authorized_keys file: one public key per line, listing every key allowed to log in as that user. On each connection sshd checks your signature against every line in it. Adding a line grants access; deleting it revokes access — no password ever involved. (You'll add your own key to it in Step 2.)

Ed25519 over RSA

Prefer ssh-keygen -t ed25519 — the keys are short, fast, and modern. Only fall back to rsa -b 4096 for ancient servers that don't support Ed25519.

~/.ssh/config — stop retyping

Instead of long ssh -i ~/.ssh/key -p 2222 ubuntu@203.0.113.10 commands, define a host alias once:

Host web
    HostName 203.0.113.10
    User ubuntu
    Port 2222
    IdentityFile ~/.ssh/devops_month

Then the whole thing collapses to one word:

ssh web                       # ≡ ssh -i ~/.ssh/devops_month -p 2222 ubuntu@203.0.113.10
ssh web 'uptime'              # run a one-off command over the alias
scp report.txt web:/tmp/      # scp, rsync, and git read this file too

Moving files: scp and rsync

Tool	Use it for
scp	Quick one-off copies over SSH — scp file user@host:/path
rsync	Syncing directories — only transfers differences, resumable, ideal for deploys

Hardening — shut the easy doors

An SSH server reachable from the internet is probed constantly by bots. Two settings in /etc/ssh/sshd_config stop the overwhelming majority of attacks:

Setting	Value	Why
PasswordAuthentication	no	No passwords to guess — keys only
PermitRootLogin	no	Force login as a normal user, then sudo

Don't lock yourself out

Before you set PasswordAuthentication no, confirm key login works in a second terminal. If keys aren't set up and you disable passwords, you can be locked out of a remote box for good. On a cloud VM, always keep one working session open while you change SSH settings.

3. VPNs — extend the private network

A VPN (Virtual Private Network) puts your machine onto a remote private network entirely, as if you were plugged in there — every app, every port, transparently. Contrast that with a single forwarded port (SSH tunneling — an advanced topic below), which reaches just one service. Companies use a VPN so employees reach internal systems from anywhere; you'll meet WireGuard (modern, fast) and OpenVPN (older, ubiquitous).

	SSH tunnel	VPN
Scope	One (or a few) forwarded ports	The whole network, all apps
Setup	Nothing extra — uses SSH	A daemon + keys on both ends
Feels like	"This local port is that remote service"	"I'm on the office network"

4. Bastion / jump hosts — one guarded front door

You don't expose every server to the internet. Instead, a single hardened, closely-watched host — the bastion (or jump host) — is the only box reachable from outside on SSH. To reach anything private, you hop through it:

You ──SSH──▶ Bastion (public IP, port 22)  ──SSH──▶  app server (private)
                                            └──SSH──▶  database  (private)

Only the bastion needs a public address and an open port; every server behind it stays unreachable from the internet, shrinking your attack surface to one heavily-monitored door. SSH makes the hop in a single command with ProxyJump — ssh -J bastion user@internal-host — without leaving your keys on the bastion.

5. Firewalls — default deny with ufw

Hardening SSH secures one door; a firewall decides which doors exist at all. Ubuntu's ufw (Uncomplicated Firewall) is a friendly front-end to the kernel's netfilter. It's stateful — replies to connections you started are allowed back automatically, so you only write rules for new inbound traffic. The golden rule: default deny inbound, allow outbound, then open only the ports you serve.

📺 Watch — Linux Firewall Tutorial: Configure Rules with UFW (Akamai, ~13 min)

A start-to-finish UFW walkthrough that mirrors this section.

Chapters: installing UFW · default rules · allow SSH first · enable UFW · allow specific IPs · deleting rules

sudo ufw allow 22/tcp             # ALLOW SSH FIRST — by port+protocol (or: ufw allow OpenSSH, see `ufw app list`)
sudo ufw allow 80,443/tcp         # HTTP + HTTPS together
sudo ufw allow from 203.0.113.7 to any port 5432   # one trusted IP (or a CIDR like 10.0.0.0/24)
sudo ufw limit 22/tcp             # rate-limit SSH: block an IP after 6 hits in 30s
sudo ufw default allow outgoing   # let the box reach out (updates, DNS…)

# ⚠ CAUTION — run ONLY after 22 is allowed above; skip it and you lock yourself out:
#   sudo ufw default deny incoming    # closes every inbound port not explicitly allowed

Rules added while ufw is inactive are only staged — nothing is enforced until enable. So build, preview, then activate — and always allow 22 before enabling, or you cut your own session:

sudo ufw show added        # list the rules you've queued
sudo ufw --dry-run enable  # print the exact ruleset enabling WOULD apply — changes nothing
sudo ufw enable            # activate

sudo ufw status numbered   # active rules, with index numbers
sudo ufw delete 3          # remove rule #3

Host firewall vs. network firewall

ufw guards this one machine. Clouds add a network firewall in front of the VM — AWS security groups, GCP firewall rules, Azure NSGs — filtering traffic before it reaches the box. They're independent, so a port must be open in both to be reachable: run the cloud firewall as the perimeter and ufw as a local backstop.

ufw — points to remember

• First match wins. Rules are checked top-to-bottom and the first one that matches decides; the default policy applies only if none do. New rules append to the end — to place one earlier, use sudo ufw insert 1 <rule>.
• Specific before general. A deny for one IP must sit above a broader allow on the same port, or the allow matches first and the deny never runs.
• allow 22 opens it to the whole internet. Scope a port with from <ip/CIDR> when only certain sources should reach it.
• Stateful — inbound rules only. Replies to connections the box started are allowed back automatically; you never write outbound rules for them.
• deny vs reject. deny drops silently (the sender just times out); reject sends back a refusal (a faster, clearer failure).
• Persists across reboots once enabled. Run sudo ufw reload after editing rules, and don't hand-edit raw iptables alongside ufw — it owns those chains.

---

Lab · ~50 min

Work inside your Vagrant VM. We'll SSH from the VM back into itself (localhost) — every command is identical to a real remote server, just without needing a second machine.

Step 1 — Generate a key pair

ssh-keygen -t ed25519 -C "devops-month" -f ~/.ssh/devops_month -N ""
#  -C comment   -f output file   -N "" no passphrase (fine for a lab)

ls -l ~/.ssh/devops_month*        # private key + .pub public key
cat ~/.ssh/devops_month.pub       # the public half — safe to share

Step 2 — Authorize the key and log in with it

Add your public key to ~/.ssh/authorized_keys — the file sshd checks on every login (one allowed key per line):

mkdir -p ~/.ssh && chmod 700 ~/.ssh
cat ~/.ssh/devops_month.pub >> ~/.ssh/authorized_keys   # append the PUBLIC key as an authorized login
chmod 600 ~/.ssh/authorized_keys

# Now log in with the KEY — no password prompt (accept the host-key prompt the first time)
ssh -i ~/.ssh/devops_month localhost 'whoami; echo "logged in with a key"'

On a real remote server, it's the same copy-paste — there's no magic

Authorizing a key is just text. You did cat ...pub >> authorized_keys here because the file is on this machine. On a remote server you do the identical thing: copy the single line cat ~/.ssh/devops_month.pub prints, and paste it onto its own line in that server's ~/.ssh/authorized_keys (through your cloud provider's web console, or an already-open session). That's the whole process. The ssh-copy-id user@host command just automates this exact paste for you — convenient, but it's nothing more than appending your public-key line.

Step 3 — Create an SSH config shortcut

cat >> ~/.ssh/config << 'EOF'

Host self
    HostName 127.0.0.1
    User vagrant
    IdentityFile ~/.ssh/devops_month
EOF
chmod 600 ~/.ssh/config

ssh self 'hostname'               # the whole connection, in one short word

Step 4 — Move files with scp and rsync

echo "deploy me" > ~/artifact.txt

scp ~/artifact.txt self:/tmp/artifact.txt        # copy one file over SSH
ssh self 'cat /tmp/artifact.txt'

mkdir -p ~/site && echo "v1" > ~/site/index.html
rsync -av ~/site/ self:/tmp/site/                # sync a directory
echo "v2" > ~/site/index.html
rsync -av ~/site/ self:/tmp/site/                # note: only the CHANGED file transfers

Step 5 — Harden the SSH server (safely)

You have a working key (Step 2), so it's now safe to turn off passwords. We use a drop-in file rather than editing the main config:

sudo tee /etc/ssh/sshd_config.d/00-hardening.conf << 'EOF'
PasswordAuthentication no
PermitRootLogin no
EOF

sudo sshd -t                                        # test config SYNTAX before applying
sudo systemctl reload ssh

sudo sshd -T | grep -i passwordauthentication       # verify the EFFECTIVE value → must print: no
ssh self 'echo "key login still works after hardening"'   # proof you're not locked out

The filename number matters — sshd keeps the first match, not the last

sshd reads its config as one stream, expanding Include /etc/ssh/sshd_config.d/*.conf (near the top of the main file) in place — and for each setting it uses the first value it sees. Ubuntu ships a 50-cloud-init.conf that sets PasswordAuthentication yes, so a 99-… file would be read too late and silently lose (password login would still work!). Naming ours 00-hardening.conf makes it read first, so it wins. This is why the sshd -T check above matters: trust the effective value, not the file. To undo: sudo rm /etc/ssh/sshd_config.d/00-hardening.conf && sudo systemctl reload ssh.

Step 6 — Lock the box down with ufw

sudo ufw allow 22/tcp                 # ALLOW SSH FIRST — or enabling locks you out
sudo ufw allow 80,443/tcp             # HTTP + HTTPS (for tomorrow's Nginx)
sudo ufw limit 22/tcp                 # rate-limit SSH: block an IP after 6 hits in 30s

sudo ufw enable                       # turn it on — inbound denied by default, outbound stays open
sudo ufw status verbose               # review the rules

curl -sI https://google.com | head -1 # confirm the box can still reach OUT (default allow outgoing)

Order matters — allow 22 before enabling

On a real remote server, enabling ufw before allowing port 22 cuts your own SSH session and locks you out. Always allow 22/tcp first. (On this Vagrant VM you'd still have vagrant ssh via the console, but build the safe habit now.)

---

Advanced Topics

• SSH agent & agent forwarding — load a key once, and use it on a jump host without copying it there → ssh-agent · ssh -A
• Jump/bastion hosts — reach a private server through a public gateway with ProxyJump → man ssh_config — ProxyJump
• SSH tunnels (local port forwarding) — reach a service that isn't exposed to the internet (a locked-down database, an internal dashboard) through your SSH connection, encrypted: ssh -L 5433:localhost:5432 user@host makes your localhost:5433 behave as the server's private 5432 → SSH tunneling explained
• fail2ban — auto-ban IPs that hammer your SSH port → fail2ban.org
• Set up WireGuard — stand up a real modern VPN between two peers → WireGuard quick start
• iptables / nftables — the raw firewall layer that ufw sits on top of → ArchWiki — nftables

---

Assignment

1. Prove the lock works. You hardened SSH in Step 5. Now see it: try to log in with a password instead of your key — ssh -o PubkeyAuthentication=no vagrant@localhost — and paste what happens. In one sentence, explain why the server turns you away. (Satisfying part: you're watching your own hardening do its job.)

2. You're the bouncer. A single server runs SSH, a website (80/443), and a private Postgres database (5432) that only the app on that same box uses. Write the ufw allow commands you'd run to open the right doors — then in one sentence say who you turned away at 5432, and why the app can still reach its database anyway.

---

Further Reading

• How SSH works — Cloudflare
• SSH tunneling explained — local, remote, and dynamic forwards
• DigitalOcean — SSH essentials
• 📺 SSH Tutorial: Crash Course (Marco Codes, ~30 min) — keys, agent, config, tunnels, and multiple Git keys, hands-on
• 📺 Linux Firewall Tutorial with UFW (Akamai, ~13 min) — the ufw workflow end to end
• man ssh, man ssh_config, man sshd_config, man ufw, man rsync
